Features:
Technical Requirement:
Design and Manufacture: KS B2361;
Face to Face: KS B2306
Flange End: KS B 1511;
Test: KS B2304;
Application:
Cast steel swing check valves are widely used in urban construction, chemical, metallurgical, petroleum, pharmaceutical, food, beverage, and environmental protection. They are selected for pipelines with a nominal pressure of PN1.6~6.4MPa and a working temperature of -29~550 ℃ in various working conditions such as petroleum, chemical, and thermal power plants. Applicable media include water, oil, steam, etc.
Details:
Parts Name | Material |
Body、Bonnet | WCB(SCPH2) |
Disc | WCB(SCPH2) |
Hinge pin | WCB(SCPH2) |
Seat ring | STS403 |
Swing Check Valve H44 | SIZE 2"-12" | PN 10K/20k |
